TappyBLE – Bluetooth + USB All-in-One NFC Reader, Writer, and Emulator
$199.99
Please note: Shipping on all orders is determined after purchase. We will contact you with your shipping quote. Orders over $500USD qualify for free shipping within Canada and the Contiguous United States.
The TappyBLE is a wireless, enterprise-grade, all-in-one NFC encoder that is easily integrated into your NFC solutions and applications. (FULL DATASHEET)
Description
What you get with the TappyBLE:
- Read and write to the most popular NFC chips (ISO 14443 A/B, Tag Types 1,2,3, and 4.)
- Focus on writing your own software application, not figuring out NFC code libraries. The Tappy includes a full NFC software stack.
- Built in NDEF reading/writing/emulation for superior scanning speed and smoother user experience
- Full software support. Includes a free open source SDK and example code for Android, iOS, Windows, and JavaScript.
- Total technical support from TapTrack, the engineers who created Tappy.
- Configurable for NFC keyboard wedge mode (Human Input Device). Native keyboard functionality. Plug and play. No driver downloads or installations.
- No cables required! Connect to your Android or iOS device wirelessly with BLE (Bluetooth Low Energy).
- Provides up to 8 hours of battery life while in use.
- Connected over Bluetooth Low Energy (BLE) , but capable of USB connectivity as well.
- Configurable for stand-alone operation.
Software Support:
| Demo Apps | Android |
| Encoding Software | Windows |
| Application Notes | TappyUSB HID (Human Input Device) True Keyboard Application Note |
| Command Reference | Download |
| Development Kits |
Product Specifications:
| Supported Standards | ISO/IEC 14443A, 14443B, 18092 |
| Supported Chips |
NFC Forum Type 1*: Topaz, Jewel
NFC Forum Type 2*: NTAG 20x, 21x, MIFARE Ultralight, Ultralight C
NFC Forum Type 4*: DESFire EV1 2K/4K/8K
MIFARE Classic 1K, 4K
(*Support any NFC Forum compliant ISO 14443 tag. The brands listed are the most common.)
|
| Frequency | 13.56 MHz |
| Max RF Outpout Power | <0.5W |
| RF Communication Speed | 106, 212, 424 kbits/s |
| Power Supply | DC 5V (from USB) |
| Battery Life | 8+ hours |
| Current | Charging: 500 mA typical |
| Read Range | 40mm typical, 100mm max |
| Interface | Bluetooth Low Energy (BLE) v5, USB2.0 |
| Status Indicator Lights |
2x RGB LED for NFC Scan Status 1x RGB LED for BLE status 1x Red LED for power status 1x Amber LED for battery charging status 1x Green LED for battery charged status |
| Working Temperature | -10°C to +70°C |
| Storage Temperature | -30°C to +80°C |
| Enclosure Dimensions | L = 12.5cm ; W = 8cm ; H = 2.5cm |
Additional information
| Weight | 0.17 kg |
|---|---|
| Dimensions | 12.5 × 8 × 2.5 cm |
